100cc 4 stroke Bicycle Engine Kit Set Gas Motorized Motor Bike Modified Engine,OHV Bicycle Engine Motor 3600rpm Single Cylinder Air Cooled Recoil Start for Mountain and Road Bike

Description

• Premium Material: The high-quality aluminum, iron, and plastic material give it good hardness, wear resistance, and durability, allowing for long-term use.
• Enjoy Riding: This kit converts your bike into a motorized bicycle, with max. speed of 3600rpm for great efficiency and convenience, allowing you to fully enjoy the fun of riding on your commute and short journeys.
• High Performance: The 4-stroke engine is more stable, more reliable, and quieter than the 2-stroke engine. Also, the 56mm bore cylinder increases the bearing capacity, and reduces the working temperature, making it easier to start, while providing continuous output over a range of speeds.
• Fits (As a Reference)For Beach Bikes with Large Triangular Frame Space

100CC Motorized Bicycle Kit Bike Engine Kit Single Cylinder 4-Stroke Gas Petrol Motorized Bike Engine Scooter
Specifications
Model: EZ-156F
Type: Forced Air Cooling, 4-Stroke, OHV, Single-cylinder, Inclined by 25 Degrees
Starting System: Recoil Start
Material: Aluminum, Iron, and Plastic
Color: Black, Silver
Max Output: 3HP
Rated Power: 2KW/3600rpm
Max. Torque: 4.5N.m/2500rpm
Fuel Tank Capacity: 1.6L/0.42gal
Fuel Consumption: <420 g/KW.h
Oil Capacity: 0.4L/0.1gal
Oil Consumption: <6.8 g/KW.h
Min. Stable Speed Unloaded: 3600rpm
Reduction Ratio: 1:1
Bore x Stroke: 56x40 mm
Displacement: 100cc
Compression Ratio: 7:1
Product Size: 28.5*35*28cm/11.2*13.7*11in
Packing Size: 73*34*25cm/28.74*13.38*9.84in
Gross Weight: 21kg/46.29lbs
Net Weight: 20kg/44lbs

Notes
1. We strongly recommend professional installation. Please contact us if you have any questions.
2. Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before you place the order.

Fits (As a Reference)
For Beach Bikes with Large Triangular Frame Space
Package Included
1* 100cc 4-Stroke Gasoline Engine
1* Fuel Tank
1* Base Bracket
1* Exhaust Pipe
1* 44 Tooth Chain
1* Chain Tensioner
1* Chain
1* Chain Guard
2* Fixed Iron Pieces
1* Spark Plug Tool
1* Fuel Line
1*Fuel Tank Cap
1 Exhaust Cushion
1* Fuel Filter
1*Fuel Valve
1* Chain Tension Adjusting Tool
1* English Manual
Other Mounting Accessories
