Description
- Electric outboard motor : The exquisite painting process and aluminum alloy improve the corrosion resistance and wear resistance of the product(able to withstand fresh and saltwater environments), which makes it can serve you for a long time.
- Strong Power: 5HP horsepower, 1200 watts power, pure copper brushless motor provides strong power to it.The simple structure and lightweight (26.45 lbs) allows you to easily install without any tools.
- Powerful Load-bearing Capacity: High-quality aluminum alloy material, powerful pure copper motor and stable structure provide an excellent load-bearing capacity of 1102-pound for you to use with peace of mind.
- Flexible Control: Having step-less speed change and constant speed function in reverse and forward gears allows you to enjoy different cruising experiences. The 180rotatable stand and omnidirectional swivel joystick allow a more flexible operation to meet different needs.
- Application:This electric outboard motor is suitable for small ships with different materials within 16.4 feet in length, such as inflatable boats, iron boats, plastic boats, fiberglass boats, and wooden boats. It is widely used in fishery, aquaculture, outdoor exploration, etc.
PanDair 48V Electric Outboard Motor Fishing Boat Engine Trolling Propeller
-Key Switch: You can turn the key to control the opening, closing, and stopping of the outboard engine, which is very convenient.
-Anti-winding Propeller: Reduce underwater resistance and improve propulsion efficiency.
-Ergonomic Handle: Its handle conforms to the ergonomic design, making it comfortable to hold.
Application:
This electric outboard motor is suitable for small ships with different materials within 16.4 feet in length, such as inflatable boats, iron boats, plastic boats, fiberglass boats, and wooden boats. It is widely used in fishery, aquaculture, outdoor exploration, etc
Specification
Model: DD-48V-1200W
Power: 1200W/5HP
Rated Voltage: 48V
Rated Current: 18A
Rated Speed: 3000rpm
No-load Speed: 4000 rpm
Process: Spray Painting
Gear Ratio: 2.08(27:13)
Control System: Tiller Control
Max. Speed: 15km/h/9.3mph
Motor Type: Pure Copper Brushless Motor
Reverse Gear: Yes
Max. Load-bearing Capacity: 500kg/1102lbs
Recommended Battery: 1*48V/4*12V (Not Included )
Propeller Model(in): 7-1/4x5-A(The size of the propeller is 7.25 inches/18.4cm, and the propelling distance of the propeller is 5 inches/12.7cm after one revolution)
Length of Suitable Ships: Less than 5m/16.4ft
Package Size: 95*42*29cm/37.4*16.53*11.41in
Product Size: 92*36.5*22cm/36.22*14.37*8.66in
Gross Weight: 14kg/30.86lbs
Net Weight: 12kg/26.45lbs
Tail Plate Height: 42cm/16.53in(Short Shaft)
Stern Plate Adapter Height: 40cm/15.74in
Package Included
1* Electric Outboard Motor
1* Propeller
1*English User Manual
2*Keys
All Accessories Needed for Installation
